Configurazione
Dalla scheda Setup:
- VoIP Service -> Basic Setup -> Primary SIP Server
- SIP Unregister: spuntare
- URI Type: SIP
- SIP Transport: UDP
- Service Domain: sip.messagenet.it
- Registrar Server Address: sip.messagenet.it
- Registrar Server Port: 5061
- Proxy Server Address: sip.messagenet.it
- Proxy Server Port: 5061
- SIP Local Port: 5060
- TLS Local Port: 5061
- Register Frequency: da 180 in su
- User Accounts
- Phone Number: 5xxxxxx
- Phone Name: a piacere (e.g. Mario Rossi)
- Authentication ID: 5xxxxxx
- Password: password del numero interno 5xxxxxx
Dalla scheda Advanced:
- Networking
- Enable STUN Server: non spuntare
- Outbound Proxy: Normalmente va lasciato vuoto. Se è il caso inserire sip.messagenet.it
- Voice Settings
- SIP Signalling
- RTP Starting Port Number: secondo le proprie preferenze
- Random RTP Port: non spuntare
- Codec Setup
- In ordine di priorità: G.729, G.711A, G.711U. Il consiglio migliore è di abilitarne il minor numero possibile
Per recuperare Username e Password, ci si può recare qui, sotto la voce Linea telefonica. La password sarà oscurata da una banda nera, accanto alla scritta "Password". Evidenziala col mouse, o cliccaci sopra due volte, e la password sarà resa visibile.
Procedure per problemi di NAT traversal
Un primo tentativo può essere effettuato agendo sull'interfaccia Web. Innanzitutto, abbassare il tempo di ri-registrazione da Setup -> VoIP Service -> Basic Setup -> Primary SIP Server -> Register Frequency a 60.
Se questo non funziona, verificare se l'abilitazione di STUN cambia qualcosa. Da Advanced -> Networking -> STUN:
- Enable STUN Server: spuntare
- STUN Server: stun.ekiga.net
- STUN Server Port: 3478
Un'ulteriore passo può essere eseguito solo connettendosi al telefono via telnet, e solo se la versione del firmware è v1.61 o v3.61. La procedura è la seguente:
- Connettersi via telnet al telefono
- comando: sip set NatkeepaliveDest sip.messagenet.it
- comando: sip set NatkeppaliveTimer 20
